Dimension Definition Standard
A1 Maximum length for road use 4616 mm
B Minimum width for road use 1227 mm
B Maximum width for road use 1951 mm
C Maximum height for road use 1803 mm
D Wheelbase 2124 mm
E Rear track minimum width 947 mm
E Rear track maximum width 1555 mm
E1 Front track minimum width 1129 mm
E1 Front track maximum width 1603 mm
F Rear overhang 1083 mm
G Ground clearance with front
ballast weight
270 mm
G Ground clearance without front
ballast weight
316 mm
H Front overhang 1409 mm
I Maximum rear slope-out angle 12°
L Maximum front slope-in angle 11°
M Front overhang without front lift 994 mm
5. Specifications
F Series 233
39940211 (555124)
