9.3 Protection stages
9 Technical data
Technical description
284
VAMP 24h support phone +358 (0)20 753 3264
VM259.EN007
Current unbalance stage I
2
> (46)
Settings:
- Setting range I
2
/ I
1
>
2 – 70 %
Definite time function:
- Operating time
1.0 – 600.0 s (step 0.1 s)
Start time
Typically 200 ms
Reset time
<450 ms
Reset ratio
0.95
Inaccuracy:
- Starting
±1%-unit
- Operate time
±5% or ±200 ms
Earth fault stage I
0
> (50N/51N)
Input signal
I
0
( input X1-7 & 8)
I
0Calc
( = I
L1
+I
L2
+I
L3
)
Setting range I
0
>
0.005 … 8.00 When I
0
0.05 … 20.0 When I
0Calc
Definite time function:
DT
- Operating time
0.08
**)
– 300.00 s (step 0.02 s)
IDMT function:
- Delay curve family
(DT), IEC, IEEE, RI Prg
- Curve type
EI, VI, NI, LTI, MI…depends on the family *)
- Time multiplier k
0.05 - 20.0, except
0.50 – 20.0 for RXIDG, IEEE and IEEE2
Start time
Typically 60 ms
Reset time
<95 ms
Reset ratio
0.95
Inaccuracy:
- Starting
±2% of the set value or ±0.3% of the rated
value
- Starting (Peak mode)
±5% of the set value or ±2% of the rated value
(Sine wave <65 Hz)
- Operating time at definite time function
±1% or ±30 ms
- Operating time at IDMT function.
±5% or at least ±30 ms **)
*) EI = Extremely Inverse, NI = Normal Inverse, VI = Very Inverse, LTI = Long Time Inverse
MI= Moderately Inverse
**) This is the instantaneous time i.e. the minimum total operational time including the fault
detection time and operation time of the trip contacts.
Earth fault stages I
0
>>, I
0
>>>, I
0
>>>> (50N/51N)
Input signal
I
0
( input X1-7 & 8)
I
0Calc
( = I
L1
+I
L2
+I
L3
)
Setting range I
0
>>
0.01 … 8.00 When I
0
0.05 … 20.0 When I
0Calc
Definite time function:
- Operating time
0.08
**)
– 300.00 s (step 0.02 s)
Start time
Typically 60 ms
Reset time
<95 ms
Reset ratio
0.95
Inaccuracy:
- Starting
±2% of the set value or ±0.3% of the rated
value
- Starting (Peak mode)
±5% of the set value or ±2% of the rated value
(Sine wave <65 Hz)
- Operate time
±1% or ±30 ms
**) This is the instantaneous time i.e. the minimum total operational time including the fault
detection time and operation time of the trip contacts.
