10. Technical Specifications
134 Green 16/18 Installation Manual
10.2 Electrical Specifications
Item Description
Power supply voltage 100 - 240 V ~
Frequency 50 / 60 Hz
Power rating 2.0 kVA
Accuracy
Tube Voltage (kVp) ± 10 %, Tube Current (mA) ±
20 %, Exposure Time (s) ± (5 % + 50 ms)
The input line voltage depends on the local electrical distribution system.
Allowable input voltage fluctuation requirement: ±10 %.
Mode of operation: non-continuous operation (NFPA 70: long time operation)
- needs waiting time (at least 60 times the exposure time) before the next
exposure begins.
Column operation time: Max. 2 min. On / 18 min. Off (Ratio 1:9)
