3. Before Installing the System
Green 16/18 Installation Manual 27
English
The digital CBCT system is based on a CMOS digital X-ray detector. The CMOS CT
detector is used to capture 3D radiographic images of the head, neck, oral surgery,
implant, and orthodontic treatment. Green16/18 can also acquire 2D diagnostic image
data in panoramic and cephalometric mode.
3.3 Unpacking Boxes
 All packaging and Styrofoam used to ship this equipment
are recyclable.
 Return the packaging to VATECH representatives or
dispose of it in compliance with the legal regulations of
your country.
3.3.1 Box No. 1 - Main Box
Component Size (mm / inch) Weight (kg / lbs.)
 Column and Rotating
Unit Assembly
 Accessories and Parts
 PC System (Optional)
 Monitor (Optional)
2100 (L) x 750 (W) x 1340 (H) /
82.7" (L) x 29.5" (W) x 52.8" (H)
274 / 604
<Main Box>
