6. Completing Miscellaneous Works
Green 16/18 Installation Manual 85
English
6. Completing Miscellaneous Works
6.1 Assembling Various Covers
6.1.1 Base Cover (Optional)
Truss Bolt
M5 x 8 – 3 pcs
(Part No. 26)
Base Cap
3 pcs
(Part No. 17)
1. Assemble the base cover and fix it with three Truss Bolts.
2. Cover 3 holes on the base with three Base Caps.
