1. Introduction
Green 16/18 Installation Manual 9
1.4 Marks and Symbols
Symbols Description Location
Dangerous voltage
Power board /
Inverter board /
Monoblock
Protective earth (Ground) Column
Off (power: disconnected to the Main
Power Switch)
Main Power
Switch
On (power: connected to the Main
Power Switch)
Main Power
Switch
Alternate current Label
Type B Applied Equipment
(IEC 60601-1: Degree of protection
against leakage current and electric
shock: Class 1 equipment)
Label
Radiation hazard Label
Indicates the authorized representative
in the European Community.
Label
The CE symbol indicates that this
product complies with the European
Directive for Medical Devices
93/42/EEC as amended by 2007/47/EC
as a class IIb device.
Label
UL mark No. E476672 Label
Caution: Federal law restricts this
device to sale by or on the order of a
licensed healthcare practitioner.
Label
Addresses where the equipment was
manufactured.
Label
