4. Installing the Equipment: Base Stand (Optional)
62 Green 16/18 Installation Manual
2. Assemble the Column Back Cover with four truss bolts.
Truss Bolt
M4 x 8 – 2 pcs
(Part No. 27)
Cross Head Screwdriver w/ Magnetic Tip 6 mm / 0.24”
3. Ensure the cables go through the Column Back Cover holes as shown in the
figure.
