10. Technical Specifications
138 Smart Plus (PHT-35LHS) Installation Manual
Item Description
Weight
Without
CEPH unit
137 kg (302.0 lbs.without Base)
190 kg (418.9 lbs.with Base)
With
CEPH unit
162 kg (357.1 lbs.without Base)
215 kg (474.0 lbs.with Base)
Total Height
Without
Base
Max. 2306.0 mm (90.8”)
With
Base
Max. 2337.5 mm (92.1”)
Dimensions
during operation
(Length x Width x
Height)
Without
CEPH unit
1144.3 (L) x 1557.5 (W) x 2306 (H)
(mm, without Base)
45.1 (L) x 61.4 (W) x 90.8 (H)
(inch, without Base)
1144.3 (L) x 1557.5 (W) x 2337.5 (H) (mm,
with Base)
45.1 (L) x 61.4 (W) x 92.1 (H)
(inch, without Base)
With
CEPH unit
1905.9 (L) x 1557.5 (W) x 2306 mm (H)
(mm, without Base)
75.1 (L) x 61.4 (W) x 90.8 (H)
(inch, without Base)
1905.9 (L) x 1557.5 (W) x 2337.5 (H)
(mm, with Base)
75.1 (L) x 61.4 (W) x 92.1 (H)
(inch, with Base)
Rotating Unit Vertical Movement Max. 803.7 mm (31.7”)
Installation Type
Base Stand/Wall Mount
(Default: Wall Mount type)
Packing Box Organization
Main Box,
CEPH Box (Optional), Base Box (Optional)
