Vatech Smart Plus PHT-35LHS Installation Manual

Appendix
Smart Plus (PHT-35LHS) Installation Manual A-5
C. Limiting the Column Height
This section explains how to limit the column height within the permissible range.
1. Measure the ceiling height in the X-ray shield room: H
ceiling
< Removing the column covers >
2. Remove two Fixing Bolts as shown in the figure.
3. Remove the Column Rear-Top Cover as shown in the figure.
