7. Setting up PC
84 Smart Plus (PHT-35LHS) Installation Manual
7.2 The Recommended PC Requirements
 It is mandatory to ensure that the PC system
configuration is compatible with the PC system
requirements for the imaging and image viewer software.
 Since image quality may be deteriorated from lack of
resources, observe the requirement guideline specified
in the following tables.
 The PC components shall be approved by UL/CSA.
 The PC shall be grounded well protectively.
 The multiple portable socket outlets shall not be placed
on the floor.
 In case the equipment is to be installed in an area with
an unstable electric power supply, it is strongly
recommended to use the AVR (automatic voltage
regulator) to keep the line voltage stable.
 The PC system provided with the Smart Plus undergoes
the rigorous test for software compatibility before
shipping. Therefore, any later changes to the hardware
and software may cause malfunction.
Item Specifications (HP)
CPU Intel Xeon W-2223 3.6 GHz 4 Core Processor
RAM 2X8GB DDR4-2400 Registered RAM
HDD 1TB SATA 7200 rpm
Graphics board NVIDIA GeForce GTX1060 6GB
Ethernet Interface
Integrated Intel I218LM PCIe GbE Controller
Intel Ethernet I210-T1 PCIe NIC (Option)
Serial Port (RS232) HP Serial Port Adapter Kit (Option)
Power Supply ≥ 700 Watts (90% efficient)
Slots
2 PCI Express Gen3 x16 slot
1 PCI Express Gen3 x 8 Slot
1 PCI Express Gen2 x 4 Slot
1 PCI Express Gen2 x 1 Slot
1 PCI 32bit/33MHz
CD/DVD drive DVD Writer 5.25"
Operating System
Windows 7 Professional 64-bit
(available through downgrade rights from Windows 10 Pro)
Recommended
System
HP Z4
