2. Choosing an Installation Site
Smart Plus (PHT-35LHS) Installation Manual 11
English
2. Choosing an Installation Site
2.1 Room Requirements
 The location of this equipment should allow for the high
visibility of the patient by the operator, and the operator
should be as about the patient as possible.
 This equipment should not be installed on thick carpets
for stability reasons.
 Anti-static floor materials should be used around the
equipment.
 The PC monitor, emergency cut-off switch, and X-ray
Exposure Switch should be installed near the operator
so that he or she can manage them simultaneously in
case of an emergency.
<Without CEPH Unit (optional): 2,044.3 mm (L) x 2,457.5 mm (W) or wider >
