3. Before Installing the System
32 Smart Plus (PHT-35LHS) Installation Manual
3.3.3 Box No. 3 – CEPH Unit (Optional)
Component Size (mm / inch) Weight (kg / lbs.)
CEPH unit
1590(L) x 820(W) x 870(H) /
62.6"(L) x 32.3"(W) x 34.3"(H)
50 / 110
Removing the cover
1. Open the box cover and remove the packing material as shown in the
figure.
