4. Installing the Equipment: Base Stand (Optional)
Smart Plus (PHT-35LHS) Installation Manual 51
Marking Points on the Wall
1. Move the equipment to the installation site as close as possible.
2. Adjust the distance between the wall and equipment by moving it slightly, so
that the wall bracket touches the wall.
3. Mark the anchor bolt locations on the wall.
Marker N/A
