4. Installing the Equipment: Base Stand (Optional)
60 Smart Plus (PHT-35LHS) Installation Manual
3. Remove the Vertical Frame Cover.
4. Remove four Safety Bolts and two Safety Brackets including the tags.
Allen Wrench 6 mm / 0.24”
Be sure not to damage the cables when removing the
bolts.
The Safety Bracket is removable only after the
Safety Bolt upon it is removed.
Bracket
To Next Page
