VECTRIX VX-2 SERVICE MANUAL
Side view of the inner backside cover
The two Phillips screws are M6 x 16mm
Assemble all parts in the other direction
Remark:
For assembling the cover please take care of the noses being in the right position
and no edge is standing out. Put in the screws slightly and if all screws and the
cover are in the correct positions tighten them.
Version 1.0/May 2011
