VECTRIX VX-2 SERVICE MANUAL
SECTION B-14:
FOOT REST
Preparations:
Disassemble Center Step-Through Cover see Section B-6
Disassemble Under Board see Section B-9
Open the two screws 1 + 2 and the two screws for the side
shields with PH2 screw driver
Same procedure for the other side if necessary
2
1
Assemble all parts in the other direction
Version 1.0/May 2011
VECTRIX, LLC
