VECTRIX VX-2 SERVICE MANUAL
SECTION C-12:
LICENSE PLATE LIGHT
Preparations:
Disassemble Rear Fender see Section B-11
Remove all cable strips
Open 2-pin connector
Unscrew the two Phillips screws with a Phillips screwdriver
PH2
Pull out the License Plate Light assembly
License Plate Bulb
Unscrew the two Phillips screws with a Phillips screwdriver
PH2
Remove plastic cover
Pull out the defect bulb
Remark:
Don’t touch the glass body of the new
bulb with the fingers, use a tissue
Assemble all parts in the other direction
Test function of license light
Version 1.0/May 2011
VECTRIX, LLC
