VECTRIX VX-2 SERVICE MANUAL
SECTION C-7:
HORN
Preparations:
Disassemble Front Fairing see Section B-1
Disassemble Front Console Cover see Section B-2
Disassemble Vertical Panel Cover-Lower see Section B-4
Disassemble Vertical Panel Cover-Upper see Section B-5
Open the connector of the horn
Unscrew the bolt by 10mm open end wrench
Assemble all parts in the other direction
Test function of Horn
Version 1.0/May 2011
VECTRIX, LLC
