VECTRIX VX-2 SERVICE MANUAL
SECTION B-16:
REAR BRAKE
Note: To replace the Rear Brake Rotor see Motor Replacement Procedure C-16
Unscrew the two inner hexagon bolts by using an Allen
key 6mm
Disassemble the rear brake
Now it is possible to exchange the brake pads
Remark
:
It is not necessary to disassemble the side cover of the
rear fork as seen on the picture
Assemble all parts in the other direction
Version 1.0/May 2011
VECTRIX, LLC
