VECTRIX VX-2 SERVICE MANUAL
SECTION C-6:
IGNITION SWITCH
Preparations:
Disassemble Front Fairing see Section B-1
Disassemble Front Console Cover see Section B-2
Disassemble Vertical Panel Cover-Lower see Section B-4
Disassemble Vertical Panel Cover-Upper see Section B-5
Remove all cable strips
Open connector
Unscrew the two fasten bolts of Key switch by 10mm
socket wrench
Assemble all parts in the other direction
Test function of the Key switch
Remark:
The lock for the seat should be changed too. Otherwise 2 different keys are
necessary.
Version 1.0/May 2011
VECTRIX, LLC
