VECTRIX VX-2 SERVICE MANUAL
SECTION C-9:
FRONT TURN INDICATOR ASSEMBLY
(Both Left and Right)
Preparations:
Disassemble Front Fairing see Section B-1
Remove all cable strips
Remove connector (2-pins) of the Turn Indicator Light
Remark:
Procedure is the same for both Turn Indicator
Lights
Unscrew the Nut from the inside with a wrench
Remove entire Front Turn Signal Assembly and pull cord
through the hole.
Replace entire Front Turn Signal Assembly
Remark:
Since the assembly is LED, you must replace
the whole assembly.
Assemble all parts in the opposite directions
Test function of Front Turn Indicator Light Assembly
Version 1.0/May 2011
VECTRIX, LLC
