VECTRIX VX-2 SERVICE MANUAL
SECTION A-1:
TOOLS NEEDED
For repairing and testing of the VX-2 scooter the following tools are needed:
Tools:
Description Specification Using for
Open wrench 5.5mm Converter
Open wrench/Turned Full-
contact (#S02445)
8mm Speedometer; Cover; Side stand; Horn
Open wrench 10mm Rear light; Front fender
Open wrench 12mm Rear shock, top; Main stand; Front brake
Open wrench 13mm Rear shock; Main stand; Front shock
Open wrench 14mm Front axle; Battery
Open wrench 16mm Front shock
Open wrench 17mm Side stand; Front axle; Battery
Open wrench 18mm Rear fork
Open wrench 19mm Rear fork
Open wrench 32mm Steering nut, top
Open wrench 45mm Steering nut, bottom
Special tool Motor nut
Torque wrench 0-20Nm
Torque wrench 10-100Nm
Spanner socket 12mm
Spanner socket 13mm
Spanner socket 14mm
Spanner socket 17mm
Allen key 2.5mm Accelerator
Allen key 4mm Plastic rear cover; Brake hose clamp; Motor
Allen key 5mm Balance weight; Controller
Allen key 6mm Front brake disc, Rear brake
Phillips screwdriver #1 Cover
Phillips screwdriver #2 Cover
Phillips screwdriver #3 Cover
Screwdriver, flat 4.5mm Front top cover
Security TORX Screwdriver TX10 Cover for electronic box
Version 1.0/May 2011
VECTRIX, LLC
