VECTRIX VX-2 SERVICE MANUAL
SECTION B-13:
FRONT WHEEL
Preparations:
Disassemble Front Fender see Section B-7
Version 1.0/May 2011
Remove both plastic covers from the screw
Open the two Hex screw with open wrench
12 mm and remove the brake
1
2
Put the scooter on a supporter and lift up the scooter until
the front wheel is moves freely
Unscrew the nut of the right side by using open wrench
17mm and hold the screw with open wrench 14mm
VECTRIX, LLC
