VECTRIX VX-2 SERVICE MANUAL
SECTION B-12:
FRONT BRAKE
Preparations:
Disassemble Front Fairing see Section B-1
Disassemble Front Console Cover see Section B-2
Disassemble Speedometer Cover see Section B-3
Disassemble Front Fender see Section B-7
Remove hex screw of the hose clamp with 8mm open
wrench
Remove the brown cables of the front brake switch and
cut all cable clamps
Unscrew both hex screws with an Allen key 5mm
Version 1.0/May 2011
VECTRIX, LLC
