VECTRIX VX-2 SERVICE MANUAL
Preparations: (for complete removal)
Disassemble Left Foot Rest see Section B-14
Disassemble Rear Suspension see Section B-18
Remove the connector from the Speedometer
Remove the two cross screws by using a Phillips
screwdriver #2 and remove the complete Speedometer
cover
Remove the two connectors from the brake switch
Remove all strips for cable and brake hose
Remove the two inner hex cap screws from the brake
lever assembly by using an Allen key 5mm
Version 1.0/May 2011
VECTRIX, LLC
