VECTRIX VX-2 SERVICE MANUAL
Move the brake hose including the complete brake lever
assembly through the frame
Attention
:
Do not open the brake system inside the scooter. The
brake liquid could damage the paint or other parts.
Move the brake hose including the complete brake lever
assembly through the frame and rear suspension
Version 1.0/May 2011
Complete removed rear brake assembly
Assemble all parts in the other directions and tighten the bolts and the nut according to the
regulated torque, see Section F-4
VECTRIX, LLC
