VECTRIX VX-2 SERVICE MANUAL
Front Fairing Complete Removal
Preparations:
Disassemble Under Board see Section B-10
Disassemble Front Fender see Section B-8
Disassemble Front Wheel see Section B-14
Hold the front cover and loosen all the connectors of the
lamps
Assemble all parts in the other direction
Remark:
For assembling the cover please take care of the noses being in the right position
and no edge is standing out. Put in the screws slightly and if all screws and the
cover are in the correct positions tighten them.
Please be sure the clamp nuts are on the right position
Version 1.0/May 2011
VECTRIX, LLC
