VECTRIX VX-2 SERVICE MANUAL
Version 1.0/May 2011
Unscrew the four Phillips bolts at the base of the Motor
Controller to remove the Motor Controller
stall new Motor Controller and re-secure with four
hillips bolts
gative Cables and Wiring Harness first
In
P
Reconnect Ne
Then replace Main Fuse and Positive Cables next
Reconnect the blue Battery Connection Cable
est functions of Sevcon Motor Controller T
VECTRIX, LLC
