VECTRIX VX-2 SERVICE MANUAL
SECTION E-3:
CHECK OF CHARGER FUNCTION
1. Normal function
If the Charger is connected and the indication led on the charger is at 60%, turn on the
scooter and the battery voltage indication of the speedometer should show 59.5 V +
1.0 V.
During the charging process at 60%, the current should be 10.0 A +
0.8 A, measured with a
clamp ampere meter on the brown wire close to the charger DC-plug.
If not, check the voltage with a digital voltmeter on the Controller power in line (red and
black thick wire). The value should be 59.5 V +
1.0 V. If yes, exchange speedometer, if not,
exchange Charger.
2. Charger didn’t start
Using a Digital Multi meter:
- Open the cover seat
- Measure on the charger connector of the scooter if the voltage is like the battery voltage
indication of the speedometer. If the voltage is zero, check the fuse #2 (30A) of the
converter or the connection cable. If the voltage is lower than 33 V check the voltage of
each battery and exchange the battery which is lower than 10.0V.
- Exchange Charger
Version 1.0/May 2011
VECTRIX, LLC
