VECTRIX VX-2 SERVICE MANUAL
SECTION F-4:
TORQUE LIST FOR BOLTS/NUTS
Description Force
Front axle self locking, nut 65 NM
Front brake housing on front shock , bolt 30 NM
Rear brake housing on rear fork, bolt 25 NM
Motor axle, nut 80 NM
Front shock, bolt 70 NM
Brake disc on front rim, bolt 25 NM
Brake disc on motor, bolt 15 NM
Ring on motor, bolt 15 NM
Handle bar, nut 50 NM
Rear fork, left and right nut 80 NM
Front fork, top nut, 32mm 60 NM
Rear shock, top bolt 45 NM
Rear shock, bottom nut 40 NM
Battery, bolt 25 NM
All plastic parts 16 kgf.cm
