CHAPTER 3
E N G I N E
DETAIL INFORMATION OF IMPORTANT PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Tapping screw for fan cover assy.
Screw for fan cover assy.
Tapping screw for top and bottom guide fan cover
Screw for top and bottom guide fan cover
Tapping screw and nut for ventilating air chamber of cylinder head cover
Bolt for cylinder head cover
Nut for double head blot on cam fixing holder
Nut for chain guide
Screw for chain adjustor
Bolt for cylinder head
Bolt for cylinder
Spark plug
Double head bolt for cylinder head inlet port
Double head bolt for cylinder head exhaust port
Nut for carburetor joint pipe
Screw for cooling fan
Screw for flywheel
Nut for magnet Assay
Screw for pick up coil
Nut for right crankcase cover
Oil filter cover cap
Nut for oil pump
Nut for oil pump sprocket
Nut for oil pump
Nut for oil pump cover
Screw for starting-clutch
Screw for super starting clutch outside
Bolt for right crankcase
Double head bolt for left and right crankcase
Fixing bolt for self start motor
Bolt for left crankcase cover and wiring harness
Tapping screw for ventilating guide board of left crankcase cover
Nut for drive disc
Nut for driven disc
Nut for driven disc clutch
Nut for press-board of kick starter
Bolt for transmission case cover
Bolt for transmission case cover
Nut for oil hole of left crank shaft.
Nut for position shaft of left crank shaft
2
2
3
1
3
4
4
1
2
2
1
1
2
2
2
4
1
2
2
9
1
2
1
2
1
1
3
2
4
2
11
4
1
1
1
1
5
2
1
1
1-3NM
10-12NM
1-3NM
10-12NM
1-3NM
10-12NM
22-25NM
10-12NM
10-12NM
10-12NM
10-12NM
10-15 NM
10-12NM
10-12NM
10-12NM
10-12NM
45-55NM
6-8NM
10-12NM
10-12NM
55-60NM
10-12NM
8-10NM
10-12NM
1-3NM
35-40NM
10-12NM
10-12NM
22-25NM
10-12NM
10-12NM
3-6NM
45-55NM
45-55NM
55-60NM
10-12NM
10-12NM
22-25NM
40-45NM
22-25NM
