VENTO MOTORCYCLES
Rev no.01/ page 21of 84
O RINGS — 7 NOS.
OIL SEALS — 4 Nos.
BEARING—13NOS
S.NO. Size (mm) Qty. Description Location
1 9Фx1.6 2 Inlet and exhaust valve guide Engine
2 13.7Фx1.5 1 Chain guide Engine
3 9.5Фx1.5 1 Chain adjustor Engine
4 18Фx3.5 1 Oil Level gauge Engine
5 30.5Фx3 1 Filter spring cap Engine
6 40.7Фx1.9 2 Driven wheel disc Engine
7 27Фx2 1 Inlet seat Engine
S.NO. Size (mm) Qty. Description Location
1 20x32x6 1 Output shaft---gearbox cover Engine
2 27x42x7 1 Output shaft—left crankcase Engine
3 20x29x6 1 Crank—left crankcase Engine
4 19.8x30x5 1 Crank—right cover Engine
S.NO. Code Qty. Description Location
1 6203 1 Output shaft—gearbox cover Engine
