PIN SHAFT—2NOS

2 6202 1 Middle shaft—gearbox cover Engine

3 6204 1 Output shaft—gearbox cover Engine

4 6004 1 Output shaft—left Crank case Engine

5 6002 1 Middle shaft—left Crank case Engine

6 6301 1 Output shaft—left Crank case Engine

7 TM-SCD4ASSCS12 1 Left crank—left Crank case Engine

8 TM-SCD4ASSCS12 1 Right crank—right Crank case Engine

8 K28x33x14 1

Crank pin—crank connecting

big end

Engine

9 K28x32x17 1 Clutch hub—clutch gear Engine

10 6902NSE28 x15x7 1 Driven disc—output shaft Engine

11 HK20 x29x18RS 1 Driven disc—output shaft Engine

12 6002 2 Camshaft— Holder Engine
