Two AC-power cords for the appliance
A envelope containing license information and a USB stick that contains the
factory ISO image.
If one or more storage shelves are included with the appliance, each storage shelf
package should contain the following:
A 3U16 storage shelf
Mounting rails for each shelf
Screws to attach the rails to the rack
Snap-in screw locks to secure the screws that attach the rails to the rack
Two AC-power cords for each shelf
Two SAS2 cords for each shelf
Removing the protective film from the 3U16
storage shelf
The 3U storage shelf ships with a clear, protective film on the top, bottom, and sides
of the chassis. You need to remove the film before you install the storage shelf into
the rack. The storage shelf does not install properly if the film is not removed.
The front panel and the rear panel do not include any film.
To remove the protective film
Warning: Make sure that another person is available to help lift the storage shelf.
1
Peel the protective film from the top of the storage shelf.
2
Lift up one end of the storage shelf and peel the film from the bottom of the
chassis.
3
When approximately half of the film is removed, lift the other end of the storage
shelf and remove the remaining film.
4
Peel the film from the sides of the storage shelf.
5
Discard all of the film.
See “Installing the 3U16 storage shelf guide rails” on page 21.
17Preparing for hardware installation
Removing the protective film from the 3U16 storage shelf
