Cables
This chapter includes the following topics:
About the cables
Connecting the VGA cable
Connecting the network cables
Connecting the appliance to one or more 3U16 storage shelves
Connecting the small form-factor pluggable (SFP+) transceivers
Connecting the power cables
About the cables
The NetBackup appliances and storage devices use the following cables.
Cables shipped with the product:
Power Distribution Unit (PDU) cords for connecting the devices to main AC
power source.
Most NetBackup appliances and storage shelves ship with two PDU compatible
cords (C13-C14). Other power cables ship to limited, specified, countries.
SAS2 cables to connect the appliance to a 3U16 storage shelf and to connect
3U16 storage shelves to each other.
SAS2-to-SAS3 cables to connect the appliance to a 2U12 storage shelf.
SAS3 cables to connect 2U12 storage shelfs to each other.
Cables which the customer must provide:
1 Gb/s network cables
10 Gb/s network cables
4
Chapter
