■ Insert the four screws (2) and secure.
13
Reinstall the appliance into the rack as needed.
■ Toward the rear of the chassis, locate the levers in the extensions on both
sides of the appliance.
■ Push up and hold the levers to release the extension locking mechanism.
■ Slide the appliance into the rack. Do not force the appliance into the rack.
■ If you disconnected the data cables, reconnect them according to the labels
you placed on them earlier.
Removing the protective film from the storage
shelf
The 3U16 storage shelf ships with a clear, protective film on the top, bottom, and
sides of the chassis. You need to remove the film before you install the storage
shelf into the rack. The storage shelf does not install properly if the film is not
removed. The front panel and the rear panel do not include any film.
Warning: Make sure that another person is available to help lift the storage shelf.
To remove the protective film
1
Peel the protective film from the top and the sides of the storage shelf.
2
Lift up one end of the storage shelf and peel the film from the bottom of the
chassis.
3
When approximately half of the film is removed, lift the other end of the storage
shelf and remove the remaining film.
Installing 3U16 storage shelves into the rack
Precautions - heavy equipment
Warning: Inappropriate handling of NetBackup components can result in serious
injury, equipment damage, or both. Use appropriate practices, techniques, and
tools when handling these components.
The heaviest devices in any equipment rack should be installed in the bottom of
the rack. If heavy devices are installed at the top of the rack, the rack may tip over.
63Adding 3U16 storage shelves to an operational NetBackup 5230 Appliance
Removing the protective film from the storage shelf
