Installing 2U12 storage shelves into the rack
Warning: Inappropriate handling of NetBackup components can result in serious
injury, equipment damage, or both. Use appropriate practices, techniques, and
tools when handling these components. The heaviest devices in any equipment
rack should be installed in the bottom of the rack. If heavy devices are installed at
the top of the rack, the rack may tip over. Injury to personnel and damage to
equipment is very possible. The storage shelf is heavier than the appliance.
Therefore, you must install the storage shelf in the bottom of the rack. Install the
appliance higher in the rack than the storage shelves.
Be sure to install all 2U12 shelves after 3U16 are installed closest to the appliance.
Storage shelf weight and dimensions
Weight: 28 kg (62 lbs)
Height: 8.89 cm (3.5") (approximately 2U)
Width: 48.3 cm (19")
Depth: 63.0 cm (24.8")
There must be a minimum depth of 76 cm (30 in.) between the front of the rack and
the rear of the rack. Veritas recommends that two people install the rails; one person
at the back of the rack and one at the front. Veritas also recommends that two
people lift and place the storage shelf into the mounted rails.
99Adding 2U12 storage shelves to an operational NetBackup 5230 Appliance
Installing 2U12 storage shelves into the rack
