Installing the 3U16 storage shelf guide rails
The 3U16 storage shelf is shipped with left and right mounting rails. These rails
install in a standard 19-inch rack. The front plates of the rails are marked left and
right. Two-inch lips on the bottoms of the rails provide a shelf on which the storage
system sits. Extenders that are built into the rails let you adjust the rails for the
depth of the rack.
Caution: Due to the weight of the units, Veritas recommends that storage shelves
be installed at or near the bottom of the rack.
Requirements
■ 19-inch equipment rack
■ Available 3U slot
■ Six M5 screws (provided)
■ Six cage nuts (provided)
■ Number 2 Phillips screwdriver
■ Flashlight
21Installing hardware into racks
Installing the 3U16 storage shelf guide rails
