VERITAS NetBackup 5230 Hardware Installation Guide

3
For more than one 3U16 storage shelf, connect the SAS_OUT ports in the first
3U16 shelf to the SAS_IN ports in the second 3U16 shelf.
4
Connect the SAS_OUT ports on the second 3U16 storage shelf to the SAS_IN
ports on the next storage shelf.
5
Connect the SAS_OUT ports of each 3U16 storage shelf to the SAS_IN ports
on the next 3U16 storage shelf.
6
Do not connect the SAS_OUT ports of the last 3U16 storage shelf to any device.
Table 4-1
Appliance and 3U16 storage shelf components
FeatureNumbers
SAS RAID PCIe card1
30Cables
Connecting the appliance to one or more 3U16 storage shelves
