REV : 2
REV DATE : 1/17
DPN003223
Page :1 /1
DOWNFLOW CW051 - CW084 W/ EC FANS & FRONT DISCHARGE
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT CW
Striated area indicates the
recommended minimum
clearance to be provided
for component access.
36"
916mm
36"
914mm
A
B
72"
1829mm
C Opening
31"
787mm
Opening
35"
889mm
33"
838mm
D
3 1/8"
79mm
F
E
16"
408mm
16"
408mm
AIR DISCHARGE
OPENING
AIR DISCHARGE
OPENING
G
DRY WEIGHT lbs. (kg)
A B C D E F G
CW051
DIMENSIONAL DATA inches (mm)CHILLED
WATER
MODEL
72 (1829)
97 (2464)
74 (1880)
99 (2515)
70 (1778)
95 (2413)
30.1 (764)
41.9 (1064)
2 (51)
8 (203)
25 (636)
28.6 (727)
25.3 (643)
28.8 (730)
FRONT VIEW
TOP VIEW
RETURN AIR
OPENING
Notes:
1. Customer piping and wiring connections
a) Standard bottom connections require unit to
be placed on a minimum of a 9" floorstand.
b) If unit is to be placed directly on the
floor, additional unit modifications are required
to relocate customer connections. Contact
your local Liebert Sales Representative.
1 3/4"
44mm
Handle
5/16"
8mm
Bezel
