Liebert Trinergy™ Cube NOTE
Page 134 Installation Manual - 10H52243IM60 - rev. 7 - 06/2020
APPENDICES
Appendix A: Current Ratings
Tables A.1, A.2 and A.3 below show the current ratings for input, output and battery.
Table A.1 Current ratings - Rectifier Input
Table A.2 Current ratings - Bypass/Output
Table A.3 Current ratings - Battery
1) Nominal rectifier AC input current (considered continuous) is based on full rated output load. Maximum current includes nominal input
current and maximum battery recharge current (considered non-continuous).
2) For breaker coordination while the module is overloaded, see the current-versus-time values on the overload curves.
3) Nominal battery voltage is shown at 2.0 volts/cell.
4) Nominal AC output current (considered continuous) is based on full rated output load.
5) Bypass AC input current (considered continuous) is based on the full rated output load.
NOTICE TO EUROPEAN UNION CUSTOMERS: DISPOSAL OF OLD APPLIANCES
This product has been supplied from an environmentally responsible manufacturer that
complies with the Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/CE.
The “crossed-out wheelie bin” symbol on the right is placed on this product to encourage you
to recycle wherever possible. Please be environmentally responsible and recycle this product
at your local recycling facility at its end of life. Do not dispose of this product as unsorted
municipal waste. Follow local municipal waste ordinances for proper disposal provisions to
reduce the environmental impact of waste electrical and electronic equipment (WEEE). For information
regarding the scrapping of this equipment please contact your closest Vertiv Representative.
CORE Rating (kVA) Voltage (VAC) Nominal Current (A) Maximum Current (A)
400 400 600 630
200 400 300 315
CORE Rating (kVA) Voltage (VAC) Nominal Current (A) Maximum Current (A)
400 400 577 635
200 400 289 318
CORE Rating (kVA) Voltage (VDC)
Maximum Battery Current, EOD (A)
240 Cells 264 Cells
400 480 1040 945
200 480 520 473
