Liebert Trinergy™ Cube MECHANICAL INSTALLATION
Page 14 Installation Manual - 10H52243IM60 - rev. 7 - 06/2020
2.9. Installation and footprint
The UPS must be installed on a level floor suitable for electronic equipment. No rear-to-wall distance is
required. The load-carrying capacity of the floor must be sufficient to support the weight of the UPS; see
technical data table (“Technical data - CORE” on page 129 and “Technical data - SYSTEM” on page 131)
for more details. Use the cable gland plate installed in the I/O BOX to secure the power cables during
installation. If this is not possible, contact the manufacturer for alternative suggestions. The maximum
system dimensions for both N or N+1 configurations using the 200 or 400kVA CORE are shown in the
tables below:
The dimensions of the various electronic equipment are shown below:
System dimensions with 200kVA
CORE (N configurations)
System
dimension
WxDxH (mm)
System
Net
Weight
(kg)
I/O Box
dimension only
(including CORE
disconnectors)
WxDxH (mm)
I/O Box weight
only (including
CORE
disconnectors)
(kg)
600A I/O Box + 2x200kVA CORES
2175x910x1950 1820 1150x910x1950 940
1200A I/O Box + 4x200kVA CORES
3975x910x1950 3180 1975x910x1950 1330
2400A I/O Box + 8x200kVA CORES
6850x910x1950 5660 2850x910x1950 1855
System dimensions with 400kVA
CORE (N configurations)
System
dimension
WxDxH (mm)
System
Net
Weight
(kg)
I/O Box
dimension only
(including CORE
disconnectors)
WxDxH (mm)
I/O Box weight
only (including
CORE
disconnectors)
(kg)
1200A I/O Box + 2x400kVA
CORES
2975x910x1950 2470 1625x910x1950 1190
2400A I/O Box + 4x400kVA
CORES
4850x910x1950 4240 2150x910x1950 1575
3000A I/O Box + 6x400kVA
CORES
7850x910x1950 7160 3800x910x1950 2820
4000A I/O Box + 8x400kVA
CORES (back-to-back)
5400x1820x1950 9265 2650x1820x1950 3945
5000A I/O Box + 10x400kVA
CORES (back-to-back)
6425x1820x1950 10875 3000x1820x1950 4225
System dimensions for redundant
configuration (N + 1)
Dimension
WxDxH (mm)
Net
Weight
(kg)
I/O Box
dimension
only
(including CORE
disconnectors)
WxDxH (mm)
I/O Box weight
only
(including
CORE
disconnectors)
(kg)
600A I/O Box + 3x200kVA CORES
3025x910x1950 2470 1500x910x1950 1080
1200A I/O Box + 5x200kVA CORES
4825x910x1950 3830 2325x910x1950 1470
1200A I/O Box + 3x400kVA
CORES
4000x910x1950 3275 1975x910x1950 1330
2400A I/O Box + 5x400kVA
CORES
5875x910x1950 5045 2500x910x1950 1715
3000A I/O Box + 7x 400kVA
CORES (in row)
8875x910x1950 7965 4150x910x1950 2960
