Liebert Trinergy™ Cube MECHANICAL INSTALLATION
Page 8 Installation Manual - 10H52243IM60 - rev. 7 - 06/2020
2.3. Pre-installation Planning
This section describes the requirements that must be taken into account when planning the positioning
and cabling of the UPS and related equipment.
Installing personnel should observer these general procedures and practices. The particular conditions
of each site will determine the applicability of such procedures.
2.4. Preliminary Checks
This section describes the requirements that must be taken into account when planning the positioning
and cabling of the UPS and related equipment.
Before installing the UPS, carry out the following preliminary checks:
• Visually examine the UPS equipment for transit damage, both internally and externally. Report
any damage to the shipper and to your Vertiv representative immediately.
• Verify that the correct equipment is being installed. The equipment supplied has an identification
tag on the interior doors stating the type, size, and main-calibration parameters of the UPS.
• Verify that the UPS room satisfies the environmental conditions stipulated in the equipment
specification, paying particular attention to the ambient temperature and air-exchange system.
2.5. Environmental Considerations
This section describes the requirements that must be taken into account when planning the positioning
and cabling of the UPS and related equipment.
2.5.1. UPS room
The UPS should be installed vertically, on a level and even concrete or other non-combustible surface,
and in an area protected from extremes of temperature and humidity. Refer to chap. 8. on page 129 and
chap. 9. on page 131 for detailed product specifications.
The UPS module is intended for indoor installation and should be located in a cool, dry, clean-air
environment with adequate ventilation to keep the ambient temperature within the specified operating
range (see chap. 8. on page 129 and chap. 9. on page 131).
The UPS is cooled with the aid of internal fans. Do not cover the ventilation openings. Cooling air must
enter and exit the cabinets freely to prevent overheating or malfunctioning.
The UPS is equipped with air filters behind the front doors. A schedule for inspection of the air filters is
required. The period between inspections will depend upon environmental conditions.
When using bottom-entry, the conduit plate must be installed.
Warning
Risk of electrical shock. Can cause injury or death. Special care must be taken when working with the
batteries associated with this equipment. When the batteries are connected together, the battery-
terminal voltage will exceed 400 VDC and is potentially lethal.
Notice
All equipment not referred to in this manual is shipped with details of its own mechanical and electrical
installation.
Notice
Risk of incorrect input power connection. Can cause equipment damage.
The standard Liebert TrinergyTM Cube Installer Guide UPS is suitable for connection to 50Hz, 3-phase,
3-wire or 4-wire plus ground input power.
Notice
Do not apply electrical power to the UPS equipment before the arrival of the commissioning engineer.
Connecting power before the commissioning engineer determines the system is properly installed may
void the warranty.
Notice
Vertiv will not accept liability or pay costs, fees, or damages arising from storing or operating the UPS
outside of the specified environmental, performance, or operating ranges and conditions as set forth
herein or in other product documentation. Please contact Vertiv Technical Support for more information.
