MECHANICAL INSTALLATION Liebert Trinergy™ Cube
Installation Manual - 10H52243IM60 - rev. 7 - 06/2020 Page 45
Figure 42 - Liebert Trinergy
TM
Cube 3000A - FRONT VIEW WITH CORE DISCONNECTORS ONE CORE
LEFT + TWO CORES DISCONNECTOR RIGHT - see “NOTE” on page 133
Figure 43 - Liebert Trinergy
TM
Cube 4000-5000A - FRONT VIEW WITH CORE DISCONNECTORS ONE
CORE LEFT + ONE CORES DISCONNECTOR RIGHT
Connectivity panel
QS44
QS2
QS9_1
QS9_2
QS9_5
QS9_6
QS4_1
QS1_1
QS4_2
QS4_5
QS4_6
QS1_6
QS1_2
QS1_5
QS4_3
QS9_3
QS9_4
QS1_3
QS4_4
QS1_4
Connectivity panel
QS44
QS2
QS9_5
QS9_6
QS4_5
QS4_6
QS1_6
QS1_5
QS4_3
QS9_3
QS9_4
QS1_3
QS4_4
QS1_4
