Original Operating Instructions: K4 edition
Document version: E – 02/2020
Installing the machine
4.3 Machine installation (scheme)
*
optional
USB cable connection
Compressed air connection
Power connection
Suction hose
Basic connections
Power connection switching unit
*
Power connection without a switching unit
2 alternatives: power connection of the suction device
Control cable of the switching unit
2 alternatives: Control of the suction device*
External compressed
air supply
Damage to the machine due to incorrect
installation
h Carry out the installation in the given order.
