Installing the machine
M9. If the working chamber door was open at step S8, close
it. If the machine does not reference as a result, quit
DentalCNC and restart the application.
M10. If DentalCNC did not determine the port number, read
how to determine the port number manually in the
documentation for the application.
4.8 Testing the machine
Aftertherstinstallationorafterare-installation,forexam-
ple after a transport, you should test the basic functions of
the machine.
M1.
Switch on the machine.
M2. Close the working chamber door.
The machine starts up. The working chamber is illu
-
minated.
M3.
Open the compressed air supply valve.
S4. Start the CAM computer and start DentalCNC.
The machine will reference. The machine is now in de
-
.
S5.
In the upper icon bar, click on the depicted
icon.
M6. Switch on the suction device and select the necessary
extraction level.
M7. If you use the recommended suction device together
with the data cable, switch the device into the “CAM-
mode”.
S8.
If the machine controls the suction device via
the data cable or a switching unit, click on the
depicted icon.
The suction device is operating and a vacuum develops
in the working chamber.
M9. With the value bars and icons depicted below, verify
that the compressed air and the vacuum in the working
chamberaresucient.
The icons display in blue when the compressed air and
thevacuumaresucient.
S10. Move the spindle to the cleaning position by
clicking on the depicted icon.
The spindle should move through the working cham
-
ber at constant speed.
S11.
Move the spindle from the cleaning position
back to the default position by clicking on the
depicted icon.
The spindle moves to the default position at constant
speed.
S12.
If the machine controls the suction device,
click on the depicted icon.
M13. Ifyoucontrolthesuctiondevicemanually,switchito.
The suction device stops operating.
M14. Open and close the working chamber door.
The working chamber door can be opened and closed
easily.
M15. If a result did not occur as described, check the follow
-
ing depending on the error:
The USB connection & USB driver installation
(
chapter 4.7 & documentation for the manufactur-
ing software)
The compressed air supply (
chapter 4.4)
The set extraction capacity of the suction device
The installation of the air extraction system (
chap-
ter
4.5, page 15)
M16. If you cannot solve a problem that occurred, contact
customer service.
