The mOSW-C1 Graphical User Interface (GUI)
C-Type GUI
MAP-200 Optical Switch mOSW-C1 Installation and User Guide Standard
June 2016 Document Number 22112369-120 R000 Page 33
Detailed View 2x2 Switch
C-Type GUI
The C-type switch is the simplest configuration of the mOSW-C1. It has one (1) input
and N outputs.
C-Type Detailed View
The screenshot below shows the GUI of the switch with the Power Trim option. You
can access a simplified view of the GUI by pressing the “Simplified GUI” button.
