Chapter 9: Specifications
mOSW-C1 Parameters
The following specifications describe the warranted characteristics of the instrument.
Table 2: mOSW-C1 M xN, N ≥ 4 Specifications
Parameter 1
1C Configuration
2D
Configuration
2E
Configuration
Wavelength Range
Single Mode
2
(SM) 1250 nm – 1650 nm
Multi Mode
3
(MM) 760 nm – 1360 nm
Insertion Loss (IL)
4
Single Mode (SM) 0.7 dB 0.7 dB 0.9 dB
Multi Mode (MM) 0.9 dB 0.9 dB 1.0 dB
Return Loss (RL)
5
Single Mode (SM) 62 dB 62 dB 60 dB
Multi Mode (MM),
OM1 (62.µm)
30 dB 30 dB 25 dB
Multi Mode (MM), OM3 (50 µm) 40 dB 40 dB 35 dB
1
All optical measurements, excluding connectors, taken after temperature has been stabilized for minimum of one hour at ambient room
temperature between 20-30°C and variation less than ±3°C.
2
For IEC 60793-2-50 Type B1.3/ ISO 11801 OS2 compliant fiber, that is Corning SMF-28e.
3
For fiber type of OM1 and OM3 fiber compliant with ISO/IEC 11801.
4
Excluding connectors. Tested at 1310nm and 1650nm for SM and 850nm and 1300nm for MM with EF compliant with IEC 62614 ED1.0
2010.
5
RL excluding connectors with 1m pigtail length. Tested at 1310nm/1625nm for SM and 850nm/1300nm for MM with EF compliant with
IEC 62614 ED1.0 2010.
