MAP-200 Optical Switch mOSW-C1 Installation and User Guide Standard
June 2016 Document Number 22112369-120 R000 Page 48
User Commands
The following table lists user commands of the mOSW-C1 cassette.
Command
Parameters
Output
Description
:ROUTe
:CLOSe
<dev>, <input>,
<output>
Set new optical connection for the
selected switch device.
:CLOSe? <dev>, <input> <output>
Query optical connection of selected
switch device
:TRIM
<dev>,<index>
(0—32)
Set trim for the switch device
:TRIM? <dev> <trim> Query trim value of the device.
:MONitor?
<dev> [,<dir>,
<input>]
<dir>, <pow> Query power value of the switch device.
:CHANnel
:DEScription
<dev>, <chnl>,
<description>
Set channel description
:DEScription? <dev>, <chnl> <description> Query channel description
:WAVelength
<dev>,
<wavelength>
Set wavelength
:WAVelength? <dev> <wavelength> Query wavelength
