:CONFig?
Description
Query configuration of all devices.
Input Format
:CONFig?
Output Format
<Device> <Type> <Maxin> <Maxout> <Latching>
<max Trim Level> <Opm> <Fiber Mode> <Fiber Core Size> <Connector
Type>
Parameter
Type
Value
Device
Numeric
1 to 8
Type
String
OSW
MaxIn
Numeric
1 to 2
MaxOut
Numeric
1 to 64
Latching
Boolean
YES / NO
Max Trim Level
Numeric
0 to 32
OPM
Boolean
YES / NO
Fiber Mode Numeric
0 : Single Mode
1 : Multi Mode
OMI 62.5 µm
2 : Multi Mode
OM3 50.0 µm
Fiber Core Size
Float
5.5um – 100um
Connector Type
String
Examples
The following examples illustrate typical responses for the CONFig?
Terminal Input:
:CONF?
Example
Terminal Response:
